ø58 Incremental Encoder with 2500 pulses per turn

ø58 Incremental Encoder with 2500 pulses per turn

Resolution is determined by glass disc

Resolution up to 2500 periods/turn

External diameter 60mm

Shaft Ø06mm

Connection by 1 meter cable

(other cable length available)

Model：AUI58-011K1R6XN

￥ 0.00
0.00

Product Description

Resolution is determined by glass disc

Resolution up to 2500 periods/turn

External diameter 60mm

Shaft Ø06mm

Connection by 1 meter cable

(other cable length available)

Model：AUI58-011K1R6XN


Mechanical Specifications

Max revolution≤ 2000 1/min
Admissible shaft load≤ 40N Axial / ≤ 80N Radial
Shaft6 mm ; 10 mm
Flange58 mm
质量约 0.3 ... 0.5 kg

Mechanica Characteristics

Interface

TTL

HTL

Power supply24 VDC
Current consumption24 V ≤ 120 mA
Impulses ≥ 100 ... ≤ 10000
ChannelsA+ ; A- ; B+ ; B- ; Z+ ;Z-
HTL 输出HTL ; 5~24 VDC
TTL 输出TTL ; 5 VDC


Environmental characteristics

RoHs compliant acc.to

IEC 62321-3-1:2013

Operating temparature-25 °C ... +75 °C
Storage temperature-40 °C ... +85 °C
Relative humidity98 % ; Non condensing
Protection class DIN EN 60529

IP65 shaft side /IP67 housing side
