ø58 Absolute Singleturn Encoder AUS58-Modbus RTU with clamping flange

ø58 Absolute Singleturn Encoder AUS58-Modbus RTU with clamping flange

Singleturn resolution up to 12 bits

Magnetic technology

External diameter 58mm

Shaft Ø10mm

Connection by 1 meter cable

(other cable length available)

Model:AUS58-A1046

0.00
0.00

Product Description

Singleturn resolution up to 12 bits

Magnetic technology

External diameter 58mm

Shaft Ø10mm

Connection by 1 meter cable

(other cable length available)

Model:AUS58-A1046


Mechanica Characteristics
Interface

SSI

Power supply24 VDC
Current consumption24 V ≤ 120 mA

Singleturn resolution

≤ 13 Bit
SSI-Clock frequency≤ 500KHz

Output code

Gray code
Shaft type Blind hole flange
Shaft diameter10mm /12mm


Environmental characteristics
RoHs compliant acc.to

IEC 62321-3-1:2013

Vibration [EN 60068-2-6]
≤100m/s 50-2000Hz
Shock [EN 60068-2-27]≤1000m/s
EMCEN 61326-1
Standard temparature-25 °C ... +85 °C
Optional temperature-40 °C ... +85 °C
Relative humidity98 % ; Non condensing
Protection class DIN EN 60529

IP65 shaft side /IP67 housing side
