ø40 Absolute Singleturn Encoder AUS40-Analog with Blind hole flange

ø40 Absolute Singleturn Encoder AUS40-Analog with Blind hole flange

Singleturn resolution up to 12 bits

Magnetic technology

External diameter 40mm

Blind hole shaft Ø08mm

Connection by 1 meter cable

(other cable length available)

Model：AUS40-C0806

￥ 0.00
0.00

Product Description

Singleturn resolution up to 12 bits

Magnetic technology

External diameter 40mm

Blind hole shaft Ø08mm

Connection by 1 meter cable

(other cable length available)

Model：AUS40-C0806

Mechanica Characteristics
Interface

4-20mA and RS485

Power supply24 VDC
Current consumption24 V ≤ 120 mA

Singleturn resolution

≤ 13 Bit

Multiturn resolution

≤ 12 Bit
Total resolution≤ 25 Bit
Voltageprogrammable
Parameter/FunctionOperating range

Function inputs

Counting directio

Velocity parameter

Shaft typeBlind hole bushing
Blind hole shaft10mm /12mm


Environmental characteristics
RoHs compliant acc.to

IEC 62321-3-1:2013

Vibration [EN 60068-2-6]
≤100m/s 10-2000Hz
Shock [EN 60068-2-27]≤1000m/s（6ms）
EMCEN 61326-1
Standard temparature-25 °C ... +85 °C
Optional temperature-40 °C ... +85 °C
Relative humidity98 % ; Non condensing
Protection class DIN EN 60529

IP65 shaft side /IP67 housing side
